Product Description
This series of grinding system is mainly used for lab powder sample and pilot sample, in order to acquire the best formula and technical parameters in mass production. It adopts the newest technology in grinding craft, mechanical drive & structure and contoling system, etc.
Features:
Low noise
Synchronization with production equipment in particle size
Reflect the actual formula effect
Imitable operating parameter of production grinding system
Easy to clean and maintain
Meeting the standards of European ATEX and PSR11
Safe to operate
Main Technical Parameter
| Model | Output(kg/h) | Main Power(kW) | Mill Speed (rpm) | Classifier Motor (kW) | Fan Power(kW) | Dimension(mm) |
| LYF-01 | 5-10 | 1.1-1.5 | 18000 | 0.37-0.55 | 2-3 | 2550*1532*2450 |
| LYF-05 | 50-60 | 3-4 | 9000 | 0.55-0.75 | 3-4 | 1900*1500*2200 |
